  • How to configure SSH on Cisco IOS. #crypto key generate rsa The name for the keys will be: R1.NETWORKLESSONS.LOCAL Choose the size of the key modulus in the range of 360 to 4096 for your General Purpose Keys. Choosing a key modulus greater than 512 may take a few minutes. It’s best to check the next generation encryption article from.
  • I have access to a couple of ASA firewalls with only ASDM access to all. I have tried to SSH to them but unable to do so despite having the correct configuration, None of the firewalls currently have a crypto key generated (i used 'show crypto key generate rsa mypubkey' using cli option in asdm).
  1. Cisco Crypto Key Generate Rsa
  2. Cisco Asr Generate Rsa Key Management
  3. Cisco Router Crypto Key Generate Rsa

Nov 23, 2011  Solved: Hi, i have a switch 2960 24TC-L with c2960-lanbasek9-mz.150-1.SE.bin and SSH v1 enabled. When i try to enable SSH v2 the swith tell me that i have to create a crypto key rsa. I generated the crypto key rsa with 1024 bits and when i try to.

KB ID 0001322

Problem

I’ve lost count of the number of times this has happened to me! Most of my colleagues prefer to use the ASDM for remote management, but if (like me) you work at command line, then sometimes people <ahem> forget to generate the RSA keypair when deploying a firewall. Then even if SSH access and AAA is setup correctly, you still can’t get in via SSH. Instead you see the following;

RoyalTS and RoyalTSX: ssh_exchange_identification: Connection closed by remote host.

PuTTY: PuTTY Fatal Error: Server unexpectedly closed network connection.

The longer the modulus, the stronger the security. A length of less than 512 bits is normally not recommended. However a longer modules takes longer to generate (see Table 12 for sample times) and takes longer to use.Cisco IOS software does not support a modulus greater than 4096 bits. I tried 'show ssh' and 'show ip ssh' but won't help.Any input will be appreciated.Hi Robert,As suggested it is not possible to check the key length but genral speaking about the modulus lenghth is When you generate RSA keys, you will be prompted to enter a modulus length. Generating keys cisco switch 1024 manual.

SecureCRT: Connection closed.

OSX/Linux: ssh_exchange_identification: Connection closed by remote host.

Rsa

Now at command line you can fix this with a ‘Crypto Key Generate RSA Modulus 2048‘ command, but you can’t get to command line only ASDM.

Solution

On older versions of the ASDM you could generate the keypair in the Identification Certificates section (well you still can but only if you are also generating a certificate request file). So, as we are command line warriors, lets use the ASDM’s command line!

Tools > Command Line Interface > Multiple Line

Send > Wait a couple of minutes and try again.

REMEMBER: I’m assuming you have SSH setup correctly if not, see the following article;

Related Articles, References, Credits, or External Links

NA

  • October 2, 2015
  • Posted by: Syed Shujaat
  • Category: Cisco, Networking Solutions

Use this command to generate RSA key pairs for your Cisco device (such as a router). keys are generated in pairs–one public RSA key and one private RSA key.

If your router already has RSA keys when you issue this command, you will be warned and prompted to replace the existing keys with new keys.

NOTE: Before issuing this command, ensure that your router has a hostname and IP domain name configured (with the hostname and ipdomain-name commands).

You will be unable to complete the cryptokeygeneratersacommand without a hostname and IP domain name. (This situation is not true when you generate only a named key pair.)

Here are the steps to Enable SSH and Crypto Key setup : 2 config must requried for SSH

1 Setup Local VTY line User ID and password

router (Config) # Line VTY 0 15

router (Config-line)# login local

router (Config-line)# Exit

!!! create local login ID/Pass
Cisco asr generate rsa key with openssl

router (Config)# username [loginid] password [cisco]

router (Config)# username loginid1 password cisco1

2. router (Config)# ip domain-name example.com

router (Config)# crypto key generate rsa

how many bits in the modulus [512] :1024

router (Config)# ip ssh version2

router (Config)# CTRL Z


Note

Secure Shell (SSH) may generate an additional RSA key pair if you generate a key pair on a router having no RSA keys. The additional key pair is used only by SSH and will have a name such as {router_FQDN }.server.

For example, if a router name is “router1.cisco.com,” the key name is “router1.cisco.com.server.”

This command is not saved in the router configuration; however, the RSA keys generated by this command are saved in the private configuration in NVRAM (which is never displayed to the user or backed up to another device) the next time the configuration is written to NVRAM.

Modulus Length

When you generate RSA keys, you will be prompted to enter a modulus length. The longer the modulus, the stronger the security. However, a longer modules take longer to generate (see the table below for sample times) and takes longer to use.

Cisco Crypto Key Generate Rsa

The size of Key Modulus range from 360 to 2048. Choosing modulus greater than 512 will take longer time.

Cisco Asr Generate Rsa Key Management

Router360 bits512 bits1024 bits2048 bits (maximum)
Cisco 250011 seconds20 seconds4 minutes, 38 secondsMore than 1 hour
Cisco 4700Less than 1 second1 second4 seconds50 seconds

Cisco Router Crypto Key Generate Rsa

Cisco IOS software does not support a modulus greater than 4096 bits. A length of less than 512 bits is normally not recommended. In certain situations, the shorter modulus may not function properly with IKE, so we recommend using a minimum modulus of 2048 bits.

Syntax Description : Optional Strings to embed with SSH Crypto key

general-keys(Optional) Specifies that a general-purpose key pair will be generated, which is the default.
usage-keys(Optional) Specifies that two RSA special-usage key pairs, one encryption pair and one signature pair, will be generated.
signature(Optional) Specifies that the RSA public key generated will be a signature special usage key.
encryption(Optional) Specifies that the RSA public key generated will be an encryption special usage key.
labelkey-label(Optional) Specifies the name that is used for an RSA key pair when they are being exported.If a key label is not specified, the fully qualified domain name (FQDN) of the router is used.
exportable(Optional) Specifies that the RSA key pair can be exported to another Cisco device, such as a router.
modulusmodulus-size(Optional) Specifies the IP size of the key modulus.By default, the modulus of a certification authority (CA) key is 1024 bits. The recommended modulus for a CA key is 2048 bits. The range of a CA key modulus is from 350 to 4096 bits.
Note Effective with Cisco IOS XE Release 2.4 and Cisco IOS Release 15.1(1)T, the maximum key size was expanded to 4096 bits for private key operations. The maximum for private key operations prior to these releases was 2048 bits.
storagedevicename:(Optional) Specifies the key storage location. The name of the storage device is followed by a colon (:).
redundancy(Optional) Specifies that the key should be synchronized to the standby CA.
ondevicename:(Optional) Specifies that the RSA key pair will be created on the specified device, including a Universal Serial Bus (USB) token, local disk, or NVRAM. The name of the device is followed by a colon (:).Keys created on a USB token must be 2048 bits or less.
CommandDescription
copyCopies any file from a source to a destination, use the copy command in privileged EXEC mode.
cryptokeystorageSets the default storage location for RSA key pairs.
debugcryptoengineDisplays debug messages about crypto engines.
hostnameSpecifies or modifies the hostname for the network server.
ipdomain-nameDefines a default domain name to complete unqualified hostnames (names without a dotted-decimal domain name).
showcryptokeymypubkeyrsaDisplays the RSA public keys of your router.
show crypto pki certificatesDisplays information about your PKI certificate, certification authority, and any registration authority certificates.
